Your position: Home > Wire Stripping Machine
150mm² Automatic Multi Core & Single Cable Cut& Stripping Machine
- Model : HS-BX09
- Wire cross-section : 1.0 – 150 mm²
- Max Wire Diameter : 30mm
- Product description: HS-BX09
Product introduction
Automatic Multi Core & Single Cable Cut& Stripping Machine
150mm²
Technical Data：
|
Machine Name |
150mm² Automatic Multi Core & Single Cable Cut& Stripping Machine |
|
Model |
HS-BX09 |
|
Dimensions (W x H x D) |
960 x 570 x 580 mm |
|
Weight |
200KG |
| Working Power |
AC220/50Hz AC110/60Hz 2000W |
|
Pneumatic connection |
Optional for blade cleaning |
|
Wire cross-sectionrange |
Max .150mm² - |
|
Wire cut length range |
200-99999mm |
|
Wire Strip length range |
Side 1(front)：0~300mm ,Side 2 (behind) : 0－150mm |
|
Length accuracy |
± (0.2 % *Length) |
|
Blades material |
Tungsten Carbide |
|
Wire transport speed |
can adjust from 1-9 |
|
Drive system |
24 Wheel drive |
|
Blade |
High Speed Steel |
|
Wire material |
PVC |
